Drum Filters Although traditionally more expensive than almost all other forms of purely mechanical filtration, Drum Filters have 2 redeeming features – the ability to consistently filter out particles down to around 50 to 90 microns and to vastly reduce maintenance and cleaning on any filter system they are fitted to. Because they take so much debris out of the water at the beginning of the filtration process, it allows the “back end” or biological part of the filter to work far more efficiently as it doesn’t have to cope with low levels of muck building up on the bacterial surfaces. This also reduces the risk of bacterial infection on your fish as there are fewer places for “bad bacteria” to propogate. The results are almost akin to getting a whole new filter.
AquaForte Prime Combi-Drum Filter
AquaForte Prime Combi-Drum Filter
The AquaForte Prime Combi-Drum Filter is the perfect combination for mechanical & biological filtration in one housing: Drum filter with moving bed. Very compact size for a total filter system, fits on 1 pallet. The Drum filter part is identical to the AquaForte Prime Drum filter XL. The moving bed module has a volume of over 200 litres and is therefore suitable for at least 100 litres of media such as the Oase Hel X or the Evolution Aqua K Range Because of the slots in the passage, the bio chamber is not suitable for Eco Pond chips. Bio media is not included. Moving bed is equipped with large membrane aerator and piping for air pump connection. Max. flow ±30m³/h.
Filtreau Combi Filter PF20 ( Pump Fed)
Filtreau Combi Filter PF20 ( Pump Fed)
Introducing the Filtreau Combi Filter PF20 (Pump Fed) drum filter, a revolutionary low-maintenance filter system designed to deliver healthy and clear water without the need for daily upkeep.
we understand the importance of efficient filtration in maintaining optimal water quality. The Filtreau Combi PF20 combines the power of a drum filter and a 250L moving-bed bio-chamber, making it suitable for (koi) ponds of up to an impressive 35,000L capacity. With this advanced system, you can enjoy the benefits of a clean and thriving aquatic environment.
Designed with convenience in mind, the Filtreau Combi Filter PF20 is equipped with one 110mm inlet and two 110mm outlets as standard. This configuration enables a water flow rate of over 20m3/h, ensuring efficient filtration and maintaining optimal water conditions for your pond.
To enhance the performance of the Filtreau Combi Filter PF20, we recommend using the TIP Cleaning Pump or Internal Rinse Pump, which are compatible with this system. These pumps facilitate easy cleaning and maintenance, allowing you to keep your filter operating at its best.
For optimal biofiltration, the Filtreau Combi Filter PF20 is designed for use with Bio Carrier Hel-X 17. This bio media provides a large surface area for beneficial bacteria colonization, ensuring effective biological filtration and supporting a healthy pond ecosystem.
The dimensions of the Filtreau Combi Filter PF20 are 93cm in length, 55.5cm in width, and 126.5cm in height, offering a compact and space-saving solution for your filtration needs.
Invest in the Filtreau Combi Filter PF20 (Pump Fed) drum filter and experience the ease of maintaining a clean and healthy pond. With its efficient filtration capabilities and low-maintenance design, this system provides exceptional performance without the need for daily interventions.
Explore the Filtreau Combi Filter PF20 (Pump Fed) drum filter today and discover how it can revolutionize your pond filtration system. Elevate your water quality and provide the best care for your valued aquatic companions. Trust in the quality and reliability of Filtreau products to create a vibrant and thriving aquatic environment.
Dimensions:
93 x 55.5 x 126.5 cm‚ (L x‚ W‚ x H)
Filtreau Combi Next
FILTREAU COMBI NEXT
The Filtreau Combi Next is a low-maintenance filter system that provides healthy, clear water, without the user having to perform daily maintenance.
The drum filter, combined with the 350L moving-bed bio-chamber and the 40W UVC Amalgam module, makes the filter suitable for (koi-)ponds up to as much as 45,000L!
The system is fitted as standard with 3 inlets (110mm) and 2 outlets (110mm). A waterflow of more than 30 m3/h can be achieved with this system!
The in/outlets are all at the front, zo even in existed situations can this filter easily be added.
The New design of this filter makes this incompatible with Certain types of media as standard like K1 as the media can slip through the grid in the bio chamber. The unit is designed to be used with Hel X 17.
Dimensions
Length: 93cm
Width: 104cm
Height: 102cm
Oase ProfiClear Premium Compact-L Pump Fed OC
Oase ProfiClear Premium Compact-L Pump Fed OC
This new compact drum filter of the ProfiClear Premium series is the inexpensive alternative for small to medium-sized bodies of water. The compact modular filter system is ideal for koi ponds up to 30 m³ in particular. Leading koi experts were consulted in developing the range. In the pumped principle, the maximum water flow through the filter is 20,000 litres per hour. With this completely self-cleaning drum filter unit, the moving bed system ensures optimal water movement and cleaning. Professional Hel-X bio-media effectively break down nutrients and pollutants in the water. A depth filtration of up to 60 microns and a new Hel-X 13 filter medium with a significantly larger surface ensure the high separation efficiency.
Features:
- High Separation Capacity through deep bed filtration up to 60 microns.
- Hel-X 13 filter media with a significantly enlarged surface area for effective decomposition of nutrients and pollutants.
- Large drum with micron 60 meshes and auto clean feature.
- Large fluidised moving bed section for maximum decomposition of pollutants.
- Can be used with the EGC Control unit.
- Auto Clean Feature.
- Control unit with digital display and temperature display.
Oase ProfiClear Premium Compact-M Gravity OC
Oase ProfiClear Premium Compact-M Gravity OC
The Oase ProfiClear Premium Compact-M OC is a self-cleaning gravity fed drum filter, offering an inexpensive alternative for smaller ponds up to 80,000 Litres.
With the inner moving bed system, the Hel-X 13 filter media provides optimal water movement and cleaning of the water and its significantly enlarged surface area offers effective decomposition of nutrients and pollutants.
This is an excellent drum filter unit that naturally integrates into the landscape even in areas where space is limited.
Product Features:
- Suitable for Ponds up to 80m3
- Innovative New Drum Filter for Smaller Ponds and Koi
- High Separation Performance with Gravity Fed Technology
- Self Cleaning Functionality
- Moving Bed System for Optimal Water Cleaning
- Hel-X 13 Filter Media Offers Effective Decomposition of Pollutants
- Can Be Easily Combined with a Bitron Gravity UVC Clarifier
Please Note: Imagery may show optional accessories not included as standard.
https://youtu.be/5j6Cgf72K08
Oase ProfiClear Premium Compact-M Pumped OC
Oase ProfiClear Premium Compact-M OC
Oase ProfiClear Premium Compact-M OC is a compact and self-cleaning pumped drum filter which offers an inexpensive alternative for smaller ponds up to 80,000 Litres.
With the inner moving bed system, the Hel-X 13 filter media provides optimal water movement and cleaning of the water and its significantly enlarged surface area offers effective decomposition of nutrients and pollutants.
This is an excellent drum filter unit that naturally integrates into the landscape even in areas where space is limited.
Product Features:
- Suitable for Ponds up to 80m3
- Innovative New Drum Filter for Smaller Ponds and Koi
- High Separation Performance with Pump Fed Technology
- Self Cleaning Functionality
- Moving Bed System for Optimal Water Cleaning
- Hel-X 13 Filter Media Offers Effective Decomposition of Pollutants
- Can Be Easily Combined with a Bitron Gravity UVC Clarifiers
Oase ProfiClear Premium DF-L Gravity OC
Oase ProfiClear Premium DF-L Gravity OC
With Oase ProfiClear Premium DF-L Gravity OC the you get professional technology through the gravity-fed rotating Drum Filter that accepts flow rates up to 33,000 litres per hour.
This filter by Oase introduces over three years of development; the drum filter module provides deep bed filtration to 60 microns and the moving bed module contains Hel-X biomedia for intelligent decomposition of pollutants and nutrients.
This outstanding, high performance filter also has a sophisticated plug & play microcontroller which digitally displays the pond water temperature and handles the self cleaning function for unique, maintenance free operation.
*Suitable for Ponds 200000 litres, fish ponds 100000 litres and Koi 45000 litres.
Product Features:
- Automatic self cleaning
- Deep bed filtration to 60 microns
- First class price/performance ratio
- Safety cut-out switch is mounted to the filter lid
- Professional filter media and moving bed process
- GRP Duroplast / stainless steel material gives the filter drum an extremely stable and durable housing.
Oase ProfiClear Premium Individual Module
Oase ProfiClear Premium Individual Module Filter
The Oase ProfiClear Premium Individual Module Filter is ideal for both professional and new pond keepers too, giving you the best water quality possible through sophisticated technology.
Premium Gravity filters are modular in design, meaning they can be connected together in separate ways in order to create a tailored system to suit virtually any pond size.
The Individual Module allows for easy installation of Aquamax Gravity Eco filter pumps or Bitron Gravity UVC products.
Pre-installed within the Filter box are stainless steel baskets for addition extra filter materials from A (active carbon) to Z (Zeolite).
DN100 pipework allows for multiple installation configurations to suit your needs with minimal pressure loss.
3-year Guarantee after registering your item with Oase.
ProfiClear Individual Module Features:
Max Flow Rate of up to 25,000 Litres Per Hour
Minimum Flow Rate of 10,000 Litres Per Hour
Includes 2x 8 Litre Stainless Steel Baskets for Filter Material
Typically used as part of a Pumping or Gravity Fed System
Oase ProfiClear Premium Moving Bed Module
Oase ProfiClear Premium Moving Bed Module
The Oase ProfiClear Premium Moving Bed Module Filter is ideal for both professional and new pond keepers too, giving you the best water quality possible through sophisticated technology.
Premium Gravity filters are modular in design, meaning they can be connected together in separate ways in order to create a tailored system to suit virtually any pond size.
The Hel -X biomedia provides adequate filtration for reliable nutrient reduction and efficient removal of toxins in the water such as ammonium, ammonia and nitrites.
3-year Guarantee after registering your item with Oase.
Features:
- Max Flow Rate of up to 25,000 Litres Per Hour
- Minimum Flow Rate of 10,000 Litres Per Hour
- Hel-X Biomedia Filtration Method
- Bypass Technology Enables Optimal Movement of the Hel-X Media during High Flow Rates
- Efficient Removal of Toxins like Ammonium, Ammonia and Nitrites
- Typically used as part of a Gravity Fed System
Oase ProfiClear Premium XL Drum Filter complete kit (Pump Fed)
Oase ProfiClear Premium XL Drum Filter – Pump Fed EGC
Based on the highly successful OASE ProfiClear Premium L Drum Filter technology, the new ProfiClear XL pond filter system can be used to filter ponds up to 530,000 Litres (or 100,000 Litre Koi Ponds). The automated Drum Module has been oversized to remove particles and pollutants even in highly sedimented ponds. The XL Drum module is offered in both pump fed and gravity fed guises.
The Pump Fed XL Filter Drum features 5 water inlets for connection to submersed AquaMax Eco Expert pumps and the new Bitron Premium Ultraviolet Clarifiers. The Pump Fed XL Drum Filter Module is supplied with intelligent filter-mounted controller for automatic cleaning of the 16 individual drum filter sieves. The filter sieves will screen out debris down to 60 microns but can be changed to optional 30 micron or 150 micron sieves depending on the level of filtration required. The Pump Fed XL drum filter can accept flow rates from 25,000 Litres/Hour up to 50,000 Litres/Hour.
Features:
- Compact and self-cleaning drum filter units available in both pump and gravity fed versions
- Premium drum filter and moving bed biological filter
- High separating capacity through deep bed filtration down to 60 microns
- New media with significantly enlarged surface area for effective decomposition of pollutants
- New pump chamber for combination with Bitron UV Clarifiers
Oase ProfiClear Premium XL Drum Filter kit
Oase ProfiClear Premium XL Drum Filter – Gravity EGC
Based on the highly successful OASE ProfiClear Premium L Drum Filter technology, the new ProfiClear XL pond filter system can be used to filter ponds up to 530,000 Litres (or 100,000 Litre Koi Ponds). The automated Drum Module has been oversized to remove particles and pollutants even in highly sedimented ponds. The XL Drum module is offered in both pump fed and gravity fed guises.
The Gravity Fed XL Filter Drum features 7 inlets for connection of up to 2 x Bitron Premium UVCs, Wall Skimmers or Bottom Drains. The 2 x 180mm outlets are designed for direct connection to the XL Moving Bed Module and/or Gravity Discharge Module. The Gravity XL Drum Filter Module is supplied with intelligent filter-mounted controller for automatic cleaning of the 16 individual drum filter sieves. The filter sieves will screen out debris down to 60 microns but can be changed to optional 30 micron or 150 micron sieves depending on the level of filtration required. The ProfiClear Gravity Fed XL Drum Filter can accept flow rates from 25,000 Litres/Hour up to 66,000 Litres/Hour.
Features:
- Compact and self-cleaning drum filter units available in both pump and gravity fed versions
- Premium drum filter and moving bed biological filter
- High separating capacity through deep bed filtration down to 60 microns
- New media with significantly enlarged surface area for effective decomposition of pollutants
- New pump chamber for combination with Bitron UV Clarifiers
Oase ProfiClear Premium XL Drum Filter kit (Pump Fed)
Oase ProfiClear Premium XL Drum Filter – Pump Fed EGC
Based on the highly successful OASE ProfiClear Premium L Drum Filter technology, the new ProfiClear XL pond filter system can be used to filter ponds up to 530,000 Litres (or 100,000 Litre Koi Ponds). The automated Drum Module has been oversized to remove particles and pollutants even in highly sedimented ponds. The XL Drum module is offered in both pump fed and gravity fed guises.
The Pump Fed XL Filter Drum features 5 water inlets for connection to submersed AquaMax Eco Expert pumps and the new Bitron Premium Ultraviolet Clarifiers. The Pump Fed XL Drum Filter Module is supplied with intelligent filter-mounted controller for automatic cleaning of the 16 individual drum filter sieves. The filter sieves will screen out debris down to 60 microns but can be changed to optional 30 micron or 150 micron sieves depending on the level of filtration required. The Pump Fed XL drum filter can accept flow rates from 25,000 Litres/Hour up to 50,000 Litres/Hour.
Features:
- Compact and self-cleaning drum filter units available in both pump and gravity fed versions
- Premium drum filter and moving bed biological filter
- High separating capacity through deep bed filtration down to 60 microns
- New media with significantly enlarged surface area for effective decomposition of pollutants
- New pump chamber for combination with Bitron UV Clarifiers
Oase ProfiClear Premium XL Gravity OC
Oase ProfiClear Premium XL Gravity OC
Based on the highly successful OASE ProfiClear Premium L Drum Filter technology, the new ProfiClear XL pond filter system can be used to filter ponds up to 530,000 Litres (or 100,000 Litre Koi Ponds). The automated Drum Module has been oversized to remove particles and pollutants even in highly sedimented ponds. The XL Drum module is offered in both pump fed and gravity fed guises.
The Gravity Fed XL Filter Drum features 7 inlets for connection of up to 2 x Bitron Premium UVCs, Wall Skimmers or Bottom Drains. The 2 x 180mm outlets are designed for direct connection to the XL Moving Bed Module and/or Gravity Discharge Module. The Gravity XL Drum Filter Module is supplied with intelligent filter-mounted controller for automatic cleaning of the 16 individual drum filter sieves. The filter sieves will screen out debris down to 60 microns but can be changed to optional 30 micron or 150 micron sieves depending on the level of filtration required. The ProfiClear Gravity Fed XL Drum Filter can accept flow rates from 25,000 Litres/Hour up to 66,000 Litres/Hour.
Features:
- Compact and self-cleaning drum filter units available in both pump and gravity fed versions
- Premium drum filter and moving bed biological filter
- High separating capacity through deep bed filtration down to 60 microns
- New media with significantly enlarged surface area for effective decomposition of pollutants
- New pump chamber for combination with Bitron UV Clarifiers
ProfiClear Premium DF-L Pump-Fed OC
ProfiClear Premium DF-L Pump-Fed OC
OASE introduces over three years of development with the ProfiClear Premium DF-L Pump-Fed OC.
With this filter you get professional technology starting with the Drum Filter Module which provides deep bed filtration to 60 microns. Then the second stage of filtration utilises the moving bed module that contains Hel-X biomedia for intelligent decomposition of pollutants and nutrients.
This outstanding, high performance filter has a sophisticated micro control system which digitally displays the pond water temperature and handles the self cleaning function for unique, maintenance free operation.
Product Features:
- Automatic self cleaning
- Deep bed filtration to 60 microns
- First class price/performance ratio
- Safety cut-out switch is mounted to the filter lid
- Professional filter media and moving bed process
- Suitable for Koi ponds and other large bodies of water to 260,000 Litres
- GRP Duroplast / stainless steel material gives the filter drum an extremely stable and durable housing.
Product Specification:
- Dimensions: 830 x 600 x 820mm
- Rated voltage: 230 V / 50 Hz
- Power consumption: 5 W
- Cable length: 2.00 + 2.00m
- Net weight: 74kg
- Guarantee (+ requested guarantee): 2 + 1 Years
- Control unit: Microcontroller
- Temperature display: Digital
- Coarse debris extraction : 60 MIM
- Automatic self cleaning: Manually
- Filter intake surface: 4200cm2
- Min. flow rate: 10000 l/h
- Max. flow rate: 25000 l/h
Aqua Forte Drum Filter
Aqua Forte Drum Filter
This all new Aqua Forte Drum Filter is a break though in both technology and price level! The first truly affordable drum filter. The Aqua Forte Drum Filter is supplied with a professional, software based controller and can be used on both pump and gravity fed systems.
The Aqua Forte Drum Filter has a low installation height of just 10cm above the water level and is a perfect solution for those wishing to go to the next level without breaking the bank.
The drum filter has three 110mm Inlet connections and two 110mm outlet connections for connecting multiple pumps or for gravity exit into a bio chamber. The waste outlet is is also 110mm in size.
The Aqua Forte Drum Filter can accommodate flow rates up to 25m³/h (5500 gallons per hour), and the controller with it’s custom software contains many safety options and functions including motor slow start, motor amp protection, manual cleaning button and standard hourly cleaning etc.
The construction of this new Drum filter is made from an injection moulded housing made of HDPE, where the white parts are made of POM (Polyoxymethylene) a hard strong polymer.
Aqua Source Synergy 35 Drum Filter
Aqua Source Synergy 35 Drum Filter
Introducing the Aqua Source Synergy Drum Filters, made by koi keepers, for koi keepers
The Aqua Source Synergy 35 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, allowing virtually maintenance free cleaning of your biological filter.
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 35,000 litres / 7,700 gallons per hour
- 2 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 728mm x 530mm x 501mm
- Drum Size (ØxW): 420mm x 415mm
Aqua Source Synergy 55 Drum Filter
Aqua Source Synergy 55 Drum Filter
Introducing the Aqua Source Synergy Drum Filters, made by koi keepers, for koi keepers
The Synergy 55 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, allowing virtually maintenance free cleaning of your biological filter.
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 55,000 litres / 12,100 gallons per hour
- 4 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 806mm x 776mm x 756mm
- Drum Size (ØxW): 620mm x 415mm
AquaForte Drum Filter XL
AquaForte Drum Filter XL
This all new Aquaforte Drum filter XL is a larger version of the popular AquaForte drum filter and a truly affordable drum filter. The Aquaforte Dum Filter is supplied with a professional, software based controller and can be used on both pump and gravity fed systems.
Advantages with the AquaForte Drum Filter XL
- The Aqua Forte Drum Filter XL is Made entirely of PP
- Extra low installing height of only 10 cm above the water level
- The controller features various security options, like a slow start for the motor and a motor security
- The controller offers more functions like a manual cleaning button and an automatic periodical cleaning process every hour
- Only one cable from controller to the drum filter. This will divide into 3 cables to the motor, float switch and cover switch
- Fitted with cover switch for extra safety
- The AquaForte Drum Filter XL is Suited for pump fed and gravity fed applications
- Maximum flow 35 m³/h
- 3 inlets of Ø 110mm and 2 outlets Ø 110mm
- Size housing (L x W x H): 62 x 62 x 55 cm
- 48 VDC Motor
- Individual, exchangeable, screen elements of 75 micron
Draco Drum Bio Unit
Draco Drum Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Standard models utilise Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- 3/4″ Ball valve drain
- Dimensions – 610mm wide x 700mm long x 680mm depth.
- Holds 100 litres of typical bio media in 185 litres of water.
- One unit capable of filtering ponds of approx. 4,000 UK gallons per unit.
https://youtu.be/eF0NysVPjz8
How does the Draco Drum Bio Unit work?
Operation of the Draco Drum Bio Unit
Draco Drum Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum large Bio Unit
Draco Drum large Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum large Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Triple 4″ inlets / twin 2″ outlets but can be modified for individual needs.
- 1.5″ Ball valve drain
- Dimensions – 740mm wide x 1140mm long x 840mm depth.
- Holds 300 litres of typical bio media and half a tonne of water.
- Double central air line.
- One unit capable of filtering ponds of approx. 10,000 UK gallons.
How does the Draco Drum large Bio Unit work?
Operation of the Draco Drum large Bio Unit
Draco Drum large Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum midi Bio Unit
Draco Drum midi Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- Dimensions – 610mm wide x 1000mm long x 705mm depth.
- Holds 200 litres of typical bio media in 300 litres of water.
- One unit capable of filtering ponds of approx. 6,000 UK gallons.
https://youtu.be/XGQjCRHyLHk
How does the Draco Drum midi Bio Unit work?
Operation of the Draco Drum Midi Bio Unit
Draco Drum midi Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum Minima Combi Unit
The Minima – Combi Unit
Another first for Draco – a true, fully functional, expandable drum combi system for under £1600.
Perfect for quarantines, average stocked ponds to 2000 gallons, multi tank / sump installations and anywhere else a complete, compact unit is needed where there is very little space as it is only 30.5cm wide.
Height above static pond water level is 17.5cm .
This unit will run gravity fed only!
Media capacity is approximately 40 litres and can take micro K1.
An additional bolt on bio unit will be available, allowing the user to seamlessly double the biological capacity of the filter.
- The integrated controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. Status of the unit is via 4 colour coded LEDs.
- Low voltage, sealed water valves and drive units utilising an extremely low geared stepper motor drive system mean that only 12 volts is anywhere near your pond water.
- Designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required). On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
Combi Unit
Dimensions (Including inlet/outlet pipes) – 350mm wide x 1215mm long x 488mm high
Height above water level – 175mm
Pond Volume – Approx 2,000 UK gallons
Single 3” inlet and outlets
recommend air pump size 40ltr
no media included
https://youtu.be/5MG-TJhXDbI
https://youtu.be/E5jc4C8a1U0
Filtreau Drum filter
Filtreau Drum filter
Now look what we have here!. A drum filter for the price of a good quality sieve. If that was not enough, these Filtreau Drum filters come complete with a built in 40watt Amalagam UV as well. There is no other prefilter available on the market that represents such a good price.
These Filtreau Drum filters have been produced to provide an entry level into the drum filter market. But the quality of these drum filters are superb for the price and represent excellent value for money.
Designed for ponds up to 5000 gallons these Filtreau Drum filters have two 4″ (110mm) inlets and one 110mm outlet for connection of the circulation pump, and one 4″ (110mm) outlet for the waste.
The drum filter comes complete with all the control gear and as mentioned above also has a 40watt Amalagam UV built in.
This drum filter, with it’s 60 micron screen will filter particles out of the ponds water automatically with the automatic cleaning process that is built into the drum. Sensors monoitor the water levels within the drum filter and a cleaning cycle is activated as and when necessary to ensure that all waste particles are removed and then flushed to waste.
There are two options available for this backwash process, you can either connect the drum up to the mains water supply and use mains water to clean the drum (a solenoid valve will be required for this option which we can supply), or a optional pressure pump can be purchased which wll be controlled by the drums built in controller and use the water held within the drum to clean the drum’s screen.
The motor that rotates the drum and the control gear have been used on other drum filters in the Netherlands and fully tested over the past 3 years so you can buy with confidence both on quality and reliablity.
The manufacturer of this Filtreau Drum filter will be shortly releasing an add on Bio-Chamber that will connect to this drum filter to provide all the biological filtration required for your pond. We will update this section as soon as they are available. This option will then enable you to have the full benefits of a Bio-Compact system which are the most cost effective and environmentally friendly forms of pond filtration available as lower wattage pumps can be used on the circulation of your ponds water.
Filtreau Moving Bed Bio Chamber
Filtreau Moving Bed Bio Chamber
The Filtreau moving-bed is a bio filtration system with a 190L bio-chamber wich ensures crystal-clear water. The moving-bed is suitable for (koi) ponds up to as much as 30.000L!
Inlets and outlets require Fitting prior to install.
Dimensions:
57 x 57 x 78 cm (L x W x H)
