Aqua Forte Drum Filter
Aqua Forte Drum Filter
This all new Aqua Forte Drum Filter is a break though in both technology and price level! The first truly affordable drum filter. The Aqua Forte Drum Filter is supplied with a professional, software based controller and can be used on both pump and gravity fed systems.
The Aqua Forte Drum Filter has a low installation height of just 10cm above the water level and is a perfect solution for those wishing to go to the next level without breaking the bank.
The drum filter has three 110mm Inlet connections and two 110mm outlet connections for connecting multiple pumps or for gravity exit into a bio chamber. The waste outlet is is also 110mm in size.
The Aqua Forte Drum Filter can accommodate flow rates up to 25m³/h (5500 gallons per hour), and the controller with it’s custom software contains many safety options and functions including motor slow start, motor amp protection, manual cleaning button and standard hourly cleaning etc.
The construction of this new Drum filter is made from an injection moulded housing made of HDPE, where the white parts are made of POM (Polyoxymethylene) a hard strong polymer.
Aqua Source Synergy 35 Drum Filter
Aqua Source Synergy 35 Drum Filter
Introducing the Aqua Source Synergy Drum Filters, made by koi keepers, for koi keepers
The Aqua Source Synergy 35 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, allowing virtually maintenance free cleaning of your biological filter.
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 35,000 litres / 7,700 gallons per hour
- 2 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 728mm x 530mm x 501mm
- Drum Size (ØxW): 420mm x 415mm
Aqua Source Synergy 55 Drum Filter
Aqua Source Synergy 55 Drum Filter
Introducing the Aqua Source Synergy Drum Filters, made by koi keepers, for koi keepers
The Synergy 55 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, allowing virtually maintenance free cleaning of your biological filter.
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 55,000 litres / 12,100 gallons per hour
- 4 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 806mm x 776mm x 756mm
- Drum Size (ØxW): 620mm x 415mm
Aqua Source Synergy Combi 100 Drum Filter
Aqua Source Synergy Combi 100 Drum Filter
Introducing the Aqua Source Synergy Combi Drum Filters, made by koi keepers, for koi keepers
The Aqua Source Synergy Combi 100 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, combined with excellent biological filtration, all in one compact unit
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel. Synergy Combi Filters have a large bio chamber and include the renowned Hel-X filter media for complete biological filtration.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 22,000 gallons per hour
- 8 x 110mm inlets and 3 x 110mm outlet
- Dry run protection
- Fully automatic Siemens Logo digital control panel, manually adjustable
- Lid with safety cut off switch ( Optional Clear Lid at extra cost)
- Overflow protection
- 70 Micron Screen with Blanketweed and debris trap fitted to drum
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Bio chamber holds 550 litres of water
- 200 litres of Hel-X media supplied ( max 275 litres)
- Air dome for bio section supplied
- Full 2 year warranty (exc Screen)
- Dimensions— External with motor and flume: 2380 x 836 x 973mm (LxWxH)
- Drum Size— 650mm diameter, 800mm length. (x2)
- Maximum Water Height – 825mm
- Installation height 14cm above water level of pond
- Approximate unit weight – 150kg
Aqua Source Synergy Combi 25 Drum Filter
Aqua Source Synergy Combi 25 Drum Filter
Introducing the Aqua Source Synergy Combi Drum Filters, made by koi keepers, for koi keepers
The Synergy Combi 25 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, combined with excellent biological filtration, all in one compact unit
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel. Synergy Combi Filters have a large bio chamber and include the renowned Hel-X filter media for complete biological filtration.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 25,000 litres / 5,500 gallons per hour
- 2 x 110mm inlets
- 1 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Bio chamber holds 135 litres of water
- 50 litres of Hel-X media supplied (Max 85 litres)
- Air curtain for bio chamber supplied
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 1020mm x 540mm x 780mm
- Drum Size (ØxW): 420mm x 215mm
Aqua Source Synergy Combi 35 Drum Filter
Aqua Source Synergy Combi 35 Drum Filter
Introducing the Aqua Source Synergy Combi Drum Filters, made by koi keepers, for koi keepers
The Aqua Source Synergy Combi 35 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, combined with excellent biological filtration, all in one compact unit
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel. Synergy Combi Filters have a large bio chamber and include the renowned Hel-X filter media for complete biological filtration.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 35,000 litres / 7,700 gallons per hour
- 3 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Bio chamber holds 450 litres of water
- 100 litres of Hel-X media supplied (Max 225 litres)
- Air dome for bio chamber supplied
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 1770mm x 685mm x 947mm
- Drum Size (ØxW): 420mm x 415mm
Aqua Source Synergy Combi 55 Drum Filter
Aqua Source Synergy Combi 55 Drum Filter
Introducing the Aqua Source Synergy Combi Drum Filters, made by koi keepers, for koi keepers
The Aqua Source Synergy Combi 55 Drum Filter is built to the highest standards and offers ultra efficient mechanical filtration, combined with excellent biological filtration, all in one compact unit
The range of Synergy Drum Filters offer a complete solution for modern filtration, with no extras to pay for. The Synergy Drums come complete with Direct Drive, magnetic safety cut off lid, 5.5 bar flushing pump complete with connections, 210nm ultra reliable motor, pull outs which allow the filter to run even if the motor fails, dry run protection and a pre-wired digital control panel. Synergy Combi Filters have a large bio chamber and include the renowned Hel-X filter media for complete biological filtration.
Aqua Source Synergy Drum Filters are covered by a 2 year warranty with spare parts available next day from stock for peace of mind.
- Flow rate of 55,000 litres / 12,100 gallons per hour
- 4 x 110mm inlets
- 2 x 110mm outlets
- Dry run protection
- 70 micron screen with blanketweed and debris trap on drum
- 110mm descending waste gutter
- Fully automatic control panel with optional manual adjustment
- Control Panel can be controlled remotely through Ethernet connection
- Lid with safety cut off switch
- 5.5 bar cleaning pump
- 210nm ultra reliable motor
- Direct drive
- Filter can still be run if the motor fails
- Bio chamber holds 550 litres of water
- 200 litres of Hel-X media supplied (Max 275 litres)
- Air dome for bio chamber supplied
- Full 2 year warranty – excluding screen
- Dimensions (LxWxH): 1941mm x 836mm x 973mm
- Drum Size (ØxW): 650mm x 415mm
AquaForte Drum Filter XL
AquaForte Drum Filter XL
This all new Aquaforte Drum filter XL is a larger version of the popular AquaForte drum filter and a truly affordable drum filter. The Aquaforte Dum Filter is supplied with a professional, software based controller and can be used on both pump and gravity fed systems.
Advantages with the AquaForte Drum Filter XL
- The Aqua Forte Drum Filter XL is Made entirely of PP
- Extra low installing height of only 10 cm above the water level
- The controller features various security options, like a slow start for the motor and a motor security
- The controller offers more functions like a manual cleaning button and an automatic periodical cleaning process every hour
- Only one cable from controller to the drum filter. This will divide into 3 cables to the motor, float switch and cover switch
- Fitted with cover switch for extra safety
- The AquaForte Drum Filter XL is Suited for pump fed and gravity fed applications
- Maximum flow 35 m³/h
- 3 inlets of Ø 110mm and 2 outlets Ø 110mm
- Size housing (L x W x H): 62 x 62 x 55 cm
- 48 VDC Motor
- Individual, exchangeable, screen elements of 75 micron
Dirty Harry Pre Filter
Dirty Harry Pre Filter
These Dirty Harry pre-filters provide you with an additional tool to keep your pond clean. The Dirty Harry pre-filter ensures that larger waste solids in the pond water, such as leaves, small branches and larger algae particles are collected before they are caught up in the pump or in the filter. By pre-filtering the water, you prevent larger particles from clogging up or overloading the filter.
They help save the service life of the pond pump is protected because large particles will not damage the impeller of the pump.
The housing of the Dirty Harry pre-filter is transparent, so it is easy to see when it needs cleaning.
The Dirty Harry pre-filter has a maximum pressure rating of 2 bar and comes complete with unions for 63 & 50mm solvent pipe, 1½” female threading and hose tails 25/32/40mm.
- Benefits of the Dirty Harry Pre-Filter
- Extra pump protection
- Transparent – Easy viewing of collected debris
- Easy to install
- 720 mm Long
- Main Body 110 mm Dia
- Max Flow 25,000 lph
Draco Drum Bio Unit
Draco Drum Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Standard models utilise Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- 3/4″ Ball valve drain
- Dimensions – 610mm wide x 700mm long x 680mm depth.
- Holds 100 litres of typical bio media in 185 litres of water.
- One unit capable of filtering ponds of approx. 4,000 UK gallons per unit.
https://youtu.be/eF0NysVPjz8
How does the Draco Drum Bio Unit work?
Operation of the Draco Drum Bio Unit
Draco Drum Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum large Bio Unit
Draco Drum large Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum large Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Triple 4″ inlets / twin 2″ outlets but can be modified for individual needs.
- 1.5″ Ball valve drain
- Dimensions – 740mm wide x 1140mm long x 840mm depth.
- Holds 300 litres of typical bio media and half a tonne of water.
- Double central air line.
- One unit capable of filtering ponds of approx. 10,000 UK gallons.
How does the Draco Drum large Bio Unit work?
Operation of the Draco Drum large Bio Unit
Draco Drum large Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum midi Bio Unit
Draco Drum midi Bio Unit was designed to co-ordinate with the Draco Drum Solum Range of drum filters, they utilise the same curved base configuration to reduce dirt traps and can be installed either singly or in multiples.
Advantages with the Draco Drum Bio Unit:
- The Design also causes the bio media to more easily circulate, thereby increasing the amount of bio media your water touches as it travels through the unit.
- Can be installed in multiple configurations to make best use of the space you have available.
- Twin 4” inlet / 2″ outlets but can be modified for individual needs.
- Dimensions – 610mm wide x 1000mm long x 705mm depth.
- Holds 200 litres of typical bio media in 300 litres of water.
- One unit capable of filtering ponds of approx. 6,000 UK gallons.
https://youtu.be/XGQjCRHyLHk
How does the Draco Drum midi Bio Unit work?
Operation of the Draco Drum Midi Bio Unit
Draco Drum midi Bio Unit unit is configured as a downward flow, diverted input unit with longitudinal air delivery, to manage water flow around the chamber, maximising the active volume for bio filtration.
Incoming water at the top will have a tendency to “track” diagonally or straight down to the outlet, the path of “least resistance”. By making it interact with the air from the bottom of the tank, this waterflow is disrupted and forced back upwards.
If part of the incoming flow is diverted towards the centre of the tank, the water is forced into the area where the air is rising, enhancing this flow disruption and pushing the water out to the sides.
As the water is pushed sideways at the surface of the unit, it has no choice but to travel downwards when it hits the side. The bottom of the chamber is curved, helping that downward flow turn into a circulatory movement. When reaching the airbar right at the bottom of the unit, the water is forced back up to repeat the circulation until it exists out of the far end. This curved bottom also eliminates any corners where debris may accumulate.
Draco Drum Minima Combi Unit
The Minima – Combi Unit
Another first for Draco – a true, fully functional, expandable drum combi system for under £1600.
Perfect for quarantines, average stocked ponds to 2000 gallons, multi tank / sump installations and anywhere else a complete, compact unit is needed where there is very little space as it is only 30.5cm wide.
Height above static pond water level is 17.5cm .
This unit will run gravity fed only!
Media capacity is approximately 40 litres and can take micro K1.
An additional bolt on bio unit will be available, allowing the user to seamlessly double the biological capacity of the filter.
- The integrated controller has start / emergency stop buttons and a knob allowing you to change the length of wash. LED indicator shows the length of time between washes in minutes. Status of the unit is via 4 colour coded LEDs.
- Low voltage, sealed water valves and drive units utilising an extremely low geared stepper motor drive system mean that only 12 volts is anywhere near your pond water.
- Designed to run without a noisy and power hungry wash pump in most circumstances (they are available if required). On standby the unit can use less than 12 watts and in full wash mode, use 35 watts. It is entirely possible to run it off a car battery for prolonged periods of time.
Combi Unit
Dimensions (Including inlet/outlet pipes) – 350mm wide x 1215mm long x 488mm high
Height above water level – 175mm
Pond Volume – Approx 2,000 UK gallons
Single 3” inlet and outlets
recommend air pump size 40ltr
no media included
https://youtu.be/5MG-TJhXDbI
https://youtu.be/E5jc4C8a1U0
EconoBead Complete System
EconoBead Complete System
Unique to the UK market, a complete plug and play filter installation consisting of Econobead EB 50 or Econobead EB 60 with by pass, Midisieve, 40 watt power UV T5 and Forza 15000 pump.
EconoBead Complete System is installed on a polymer pallet. This only needs 3 connections to the pond system.
- Inlet from Bottom Drain
- Return to Pond
- Waste Outlet
Pallet size is 100 cm x 120 cm x 85 cm High.
Econobead EB 50 is suited for ponds up to 20000 ltrs (4400 gallons)
Econobead EB 60 is suited for ponds up to 30000 ltrs (6600 gallons)
The EconoBead Bead filters are the economical answer to imitation filters, made by the Beadfilter experts!
The EconoBead Beadfilters have a strong quality polypropylene vessel and are standard equipped with:
- A drain valve to remove the sludge from the bottom of the Econobead
- A 6 way valve
- A very reliable blower
- The blower is also equipped with a silencer.
The UltraSieve Midi is a Gravity Fed pre-filter to filter waste solids from the water via a bottom drain or through a skimmer. This technique is based upon the very successful Ultrasieve III, which incorporates a sieve-bend. A sieve-bend consists of hundreds of sharp stainless steel profile wires with very small slot openings where the water can go through but the solids stay on the sieve bend. In practice it works as follows:
The water enters the Ultrasieve Midi via the Ultraskim or bottom drain and passes through the “auto-adjustable” dam and will go upwards and fall over the weir on to the Stainless Steel sieve-bend.
Kockney Koi 10000V Fibreglass Filter
Kockney Koi 10000V Fibreglass Filter
The KF10000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 10,000 litres and a maximum flow rate of 6,000 litres ph. However, with lighter stocking densities or in fish free ponds the KF10000 will comfortably cope with larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals
The media package consists of:
Specifications:
Bay 1: Six 16″ long x 8″ diametre polypropylene filter brushes – They are of a semi-rigid construction with a wire loop at the end for easy installation.
Bay 2: Blue matting – This is an excellent filter media as it has excellent bio-mass retention and its open texture removes larger particles from the water.
Bay 3: Six layers of sponge with varying layers of porosity, two large foam blocks and a layer of flocor.
Bay 4: Filled with Flocor. The large surface area of Flocor tubes makes it an ideal filter media.
81” long x 21” wide x 24” Deep
Maximum flow rate 6,000 litre per hour
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Supplied with 3 1.5″ Kockney Koi Ball Valves
The pump fed model has a 4″ inlet and outlet while the gravity fed model has a 4″ inlet and 1.5″ outlet.
Both Options are supplied including media
Kockney Koi 18000V Fibreglass Filter
Kockney Koi 18000V Fibreglass Filter
The KF18,000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber design ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of 18,000 litres and a maximum flow rate of 11,000 litres per hour. However, with lighter stocking densities or in fish free ponds the KF18,000 will comfortably cope with much larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals
Specifications:
The media package consists of:
Bay 1: Eighteen 16″ long x 8″ diametre polypropylene filter brushes – They are of a semi-rigid construction with a wire loop at the end for easy cleaning.
Bay 2: Blue matting – This is an excellent filter media as it has a large surface area giving it an excellent bio-mass retention. Its open texture removes larger particles from the water.
Bay 3: Three layers of reticulated foam with different density of porosity of each layer. This is on top of a layer of approximately 2 cubic foot of flocor.
Bay 4: Six way foam block manifold assembly on top of six cubic foot of Flocor. The large surface area of Flocor tubes makes it an ideal filter media.
102 ” long x 33” wide x 32” Deep
Maximum flow rate 11,000 litre per hour
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Supplied with 3 x 1.5″ Kockney Koi Ball Valves (Not shown)
The gravity fed model has a 4″ inlet and 1.5″ outlet where the pump fed model has a 1.5″ inlet and 4″ outlet.
Both Options are supplied including media
Kockney Koi 5000V Fibreglass Filter
Kockney Koi 5000V Fibreglass Filter
The KF 5000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 5000 litres and a maximum flow rate of 3000 litres ph. However, with lighter stocking densities or in fish free ponds the KF4000 will comfortably cope with larger volumes. Complete with a new media package consisting of: filter brushes, Japanese matting, wadding and flocor. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals. It is suitable for Pump or Gravity feed. Fitted with 3″ inlet and 2″ outlet. Pump fed version comes complete with 2 x 2″ outlets.
Specifications:
5000V (4 Bay) 51” x 17” x 19” Deep
Maximum flow rate 3,000 litre per hour
Inlet size 3” – Outlet 2” solvent (pump fed 2 x 2″ outlets)
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Media: flocor, matting cartridge, brushes, and filter wadding
Both Options are supplied including media
Kockney koi 8000 Fibreglass Filter
Kockney koi 8000 Fibreglass Filter
The KF8000 is available as pump fed (KF8000P) and gravity fed (KF8000G). It is a high quality, free-standing, fibreglass, three bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 8000 litres and a maximum flow rate of 6000 litres ph. However, with lighter stocking densities or in fish free ponds the KF8000 will comfortably cope with much larger volumes. Complete with multi spray bar (pump fed), filter brushes, Japanese matting and flocor. Its clever design enables it to fit through a standard 30″ domestic door opening (if required) so it can be transported through the house for those properties where there is no side or rear access. Optional matching vortex (VF1) available for gravity fed model (KF8000G).
Specifications:
8000 Litre (3 Bay) 37″ x 31.5″ x 24.5″ Deep
Maximum flow rate 6,000 litre per hour
Pump fed – Inlet size 1.5” – Outlet 110mm solvent
Gravity fed – inlet size 110mm – outlet 1.5”
Available as gravity or pump fed complete with: 2 drains and 2 Ball Valves
Media: flocor, blue matting cartridge and brushes
Both Options are supplied including media
Kockney Koi Filter 4000
Kockney Koi Filter 4000
The 4000FG is a Pump Fed, high quality, free-standing, fibreglass, four bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for ponds of up to 4000 litres and a maximum flow rate of 3000 litres ph.
However, with lighter stocking densities the KF 4000 will comfortably cope with larger volumes. 1.5” inlet & 2” Outlet. Complete with multi spray bar, filter brushes, Japanese matting and flocor.
Specifications:
4000 Litre (4 Bay) 36” x 17” x 19” Deep
Maximum flow rate 3,000 litre per hour
Inlet size 1.5” – Outlet 2” solvent
Available pump fed with spray bar complete with or without media
Two drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Media: flocor, matting cartridge, brushes, filter wadding
Supplied including media
Nexus 220+ Filter
The Nexus 220+
Evolution Aqua have launched the Nexus320+ and Nexus220+ filtration systems. Building on the tried and tested technology that has been ever present in the world renowned Nexus, the team at Evolution Aqua have gone even further to enhance their number one Koi pond filter.
The Nexus320+ and Nexus220+ filters now come with a new filter media called K+ Media in the moving bed outer chamber for vastly improved biological filtration and faster filter maturation. The new Nexus+ filters are also supplied “auto ready”, with factory fitted fixings already in place, making it even easier to upgrade to the Nexus Automatic Cleaning System.
Technical Data:
- Maximum pond size: 18,000 litres / 4,000 gallons
- Recommended flow rate: 6,000 litres per hour
- Maximum flow rate: 10,000 litres per hour
- Volume of water in Nexus: 510 litres
- Amount of K1 Micro in EAZY: 18 litres
- Amount of K+Media supplied: 50 litres
- Maximum amount of K+Media: 150 litres
Nexus 220 Filter Lid
The Nexus 220 Filter Lid
The Nexus 220 Filter Lid is vey light weight and very durable and UV resistant. They fit perfectly on top of the Nexus Eazy 220 & Nexus Eazy 320 systems.
The lids are very well made, robust and of course will with-stand the outside weather conditions as well, but more importantly it will keep out light as well as debris which will effect the Bio mass inside the Nexus Eazy 220 Filters.
Simply a must when buying the Nexus Eazy 220 or Nexus Eazy 320 filters.
Nexus 320+ Filter
The Nexus 320+
Evolution Aqua have launched the Nexus320+ and Nexus220+ filtration systems. Building on the tried and tested technology that has been ever present in the world renowned Nexus, the team at Evolution Aqua have gone even further to enhance their number one Koi pond filter.
The Nexus320+ and Nexus220+ filters now come with a new filter media called K+ Media in the moving bed outer chamber for vastly improved biological filtration and faster filter maturation. The new Nexus+ filters are also supplied “auto ready”, with factory fitted fixings already in place, making it even easier to upgrade to the Nexus Automatic Cleaning System.
Technical Data:
- Maximum pond size: 34,000 litres / 7,500 gallons
- Recommended flow rate:11,000 litres per hour
- Maximum flow rate:13,000 litres per hour
- Volume of water in Nexus:840 litres
- Amount of K1 Micro in EAZY:20 litres
- Amount of K+Media supplied:100 litres
- Maximum amount of K+Media:300 litres
Nexus 320 Filter Lid
The Nexus 320 Filter Lid
The Nexus 320 Filter Lid is vey light weight and very durable and UV resistant. They fit perfectly on top of the Nexus Eazy 220 & Nexus Eazy 320 systems.
The lids are very well made, robust and of course will with-stand the outside weather conditions as well, but more importantly it will keep out light as well as debris which will effect the Bio mass inside the Nexus Eazy 220 Filters.
Simply a must when buying the Nexus Eazy 220 or Nexus Eazy 320 filters.
Eazy Pod Grey
Eazy Pod Grey
Easy to use filter system
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres.
The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter.
Available in Grey or Granite Green colours.
Overview
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres. The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter. Also available as Eazy Pod Air models, which come supplied with AirPump70 Kit.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size: 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 Micro media: 18 litres included
- Recommended Air Pump: 70 litres
Eazy Pod Air Green
The Eazy Pod Air Green
The Eazy Pod Air Green, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Green, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Green for smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: 40 litres
Eazy Pod Air Grey
The Eazy Pod Air Grey
The Eazy Pod Air Grey, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Grey, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Green for smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: 40 litres
Eazy Pod Filter Kit for koi pond (set)
Eazy Pod Filter Kit for koi pond
At Cotswold koi We understand that sometimes it can be confusing as to knowing what equipment you require for your pond, So we have put together this kit which will make your life a 100% easier. This Eazy Pod filter kit is recommended for koi ponds 1000-1500 uk gallons or up to 2200 uk gallons on lightly stocked ponds.
Eazy Pod Air Grey
The Eazy Pod Air Grey, best small pond filter just got better ! Due to popular demand the Eazy Pod is now also available with an Airtech 70 Air Pump kit.
Introducing the Eazy Pod Air Grey, yes that’s right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones.
The Eazy pod Air Greyfor smaller ponds has unparalleled results, the Eazy Pod Air is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy pod Air Features:
- is a complete filter and air Pump system for smaller ponds with unparalleled results
- comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones
- is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- works equally well pump or gravity fed
- also comes with a compact lid as standard.
This is a set kit to customise click here
Contct us if you require help build a kit for your protect
Eazy Pod Complete Green
The Eazy Pod Complete Green
The Eazy Pod Complete Green (complete with 18 watt Uv) Eazy, best small pond filter just got better ! Due to popular demand the Eazy Pod Air Uv Complete is now also available with an Airtech 70 Air Pump kit and built in 18 watt Uv.
Introducing the Eazy Pod Complete Green, yes thats right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and a built in 18 watt UV
Eazy Pod Complete Green for smaller ponds has unparalleled results, the Eazy Pod Air UV Complete is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
Eazy Pod Complete Green with 18 Watt UV Features:
- Complete is a complete filter and air Pump system for smaller ponds with unparalleled results
- Complete comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and 18 watt UV
- Complete is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- Complete has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With the Eazy Pod their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- Complete for pump fed applications only
- Complete also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: Airtech 40 litres
Eazy Pod Complete Grey
Eazy Pod Complete Grey
The Eazy Pod Complete Grey (complete with 18 watt Uv) Eazy, best small pond filter just got better ! Due to popular demand the Eazy Pod Air Uv Complete is now also available with an Airtech 70 Air Pump kit and built in 18 watt Uv.
Introducing the Eazy Pod Complete Grey, yes that’s right the kit includes a Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and a built in 18 watt UV
TheEazy Pod Complete Grey for smaller ponds has unparalleled results, the Eazy Pod Air UV Complete is the latest to come from the Evolution Aqua stable and is set to meet the challenge of today’s koi Pond enthusiast.
The Eazy Pod Air UV Complete with 18 Watt UV Features:
- Complete is a complete filter and air Pump system for smaller ponds with unparalleled results
- Complete comes complete with Airtech 70 Air Pump, manifold, 10m airline & 2 air stones and 18 watt UV
- Complete is a small filter (only 23 inches tall) utilising proven Nexus Eazy success
- Complete has a Quick and eazy cleaning cycle with the supplied Airtech 70 Air Pump
- With the Eazy Pod their is no wet or dirty hands
- comes complete with adjustable rubber connectors (all pipework up to 3 inch)
- Complete for pump fed applications only!!!!!!!
- Complete also comes with a compact lid as standard.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 media: 25 litres included
- Recommended Air Pump: Airtech 40 litres
Eazy Pod Green
Eazy Pod Green
Easy to use filter system
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres.
The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter.
Available in Grey or Granite Green colours.
Overview
A compact member of the Nexus family, the Eazy Pod is a mechanical and biological filter system for ponds up to 10,000 litres. The Eazy Pod utilises 18 litres of static K1 Micro, which provides enhanced biological benefits, even when using the Eazy Pod solely as a mechanical waste filter. Also available as Eazy Pod Air models, which come supplied with AirPump70 Kit.
- Max Pond Size: 20,000 Litres
- Max Koi Pond Size: 10,000 Litres
- Maximum garden pond flow rate: 10,000 lph
- Maximum Koi Pond flow rate: 5,000 lph
- Kaldnes K1 Micro media: 18 litres included
- Recommended Air Pump: 70 litres
