Description
AquaMax Eco Titanium 31000
The Eco Titanium 31000 is an energy-efficient gravity filter pump for large bodies of water, also with koi stock – perfect for gravity filter systems. Thanks to the flow-optimized hydraulics, the power pack achieves an outstanding level of efficiency (31,500 l / h delivery rate with a power consumption of only max. 170 W). With a robust pump housing made of cast stainless steel and a large base for secure placement. The high-quality SIC ceramic of the rotor shaft and the bearings stand for reliability and durability. The AquaMax Eco Titanium 31000 can be immersed and set up dry – also ideal in a pump chamber. It conveys coarse dirt with a grain size of up to 6 mm and is reliably protected against dry running and blockage thanks to “Environmental Flow Control” (EFC by OASE). The patented “Seasonal Flow Control” (SFC) as an intelligent and environmentally conscious regulation of the water volume and delivery height enables additional energy savings of up to 30% with the help of optional accessories and with the SFC function switched on – precise and reliable engineering “Made in Germany” at a particularly high level . Up to 5 years guarantee – 3 plus 2 years requirement guarantee.
Characteristics:
- Innovative gravity filter pump for large bodies of water with koi stock
- With flow-optimised hydraulics achieves an outstanding level of efficiency of over 50%
- With innovative AquaMax Eco Control for bi-directional control of the pump via 10 m DMX-RDM cable
- Protection against dry run and blocking through Environmental Function Control (EFC by OASE)
- Patented Seasonal Flow Control (SFC) for intelligent and environmentally-conscious regulation of flow rate and pump head
- An additional 30% energy savings is possible with SFC switched on
- Ideal for set-up in a pump chamber
- Can be set up underwater & dry
- AquaMax Eco Titanium 31000 Pumps coarse debris up to 6 mm in size
- Robust pump housing of cast stainless steel with large pedestal for secure placement
- Rotor shaft and bearings of high-quality SIC ceramics for optimal reliability and long service life
- MADE IN GERMANY: precise and reliable German engineering at a high level of quality
Robust pump housing
Cast stainless steel enables achievement of sustainable precision and energy-efficiency. The entire pump housing can be adjusted 90° upward.
Special channel-type impeller
The impeller has a long service life. Even under continuous load, signs of wear cannot be detected.
Connection for EGC
Innovative and convenient, the pump can be regulated and operated through control devices such as the Eco Control (included in the scope of delivery).
Technical Data
| Dimensions (L x W x H) | mm | 275 x 175 x 215 |
|---|---|---|
| Rated voltage | 220 – 240 V / 50/60 Hz | |
| Power consumption | W | 35 – 170 |
| Power cable length | m | 10.00 |
| Net weight | kg | 9.20 |
| Guarantee (+ request guarantee) | Years | 3 + 2 |
| Max. flow rate | l/min | 525 |
| Max. flow rate | l/h | 31500 |
| Max. head height | m | 3.30 |
| Connection pressure-side | mm | 63 |
| Connection pressure-side | 2 ½” | |
| Connection sunctions-side | mm | 63 |
| Connection sunctions-side | 2 ½” | |
| Coarse debris displacement max. | mm | 6 |
| Connection EGC | Yes | |
| Electronically adjustable | Yes | |
| Setup type | Can be setup underwater & dry |
