Evolution Aqua Evo UV 110 watt

Bio-UV 40 professional UVC unit

The Bio UV Professional is probably the worlds best UV system made from 316L Stainless Steel. With a 6″ Body and 2-3″ returns for today’s high flow system. The Bio UV Professional incorporates a single lamp for ponds up to 30,000 gallons, with a long life lamp of 9000 hours. All units are IPS4 rating. Kills 99.9% of algae spores, bacteria and viruses.

How the Bio-UV 40 professional UVC unit works

It has been long known that ultraviolet lamps at a wavelength of 254 nanometers, or 2537 Angstrom, have high bactericidal, virucidal and algicidal properties. Type C ultraviolet eradicates germs by aggressively disrupting the cell metabolisms leading to their destruction. These lamps should not be mistaken for ozone producing lamps, which operate at different wavelengths. Ultraviolet radiation is measured in micro watts/second/cm2.

The key elements for efficient disinfecting are based, on one hand on the exposure time (i.e the ratio between the size of the pond and the flow rate through the filter) , and on the other hand, on the energy emitted in micro watts/second/cm2 at the furthest point from the lamp. Performance is measured in milijoules (mj) by combining the energy emitted by the lamp and the exposure time. The Bio UV range UV-C lamps work at levels above the minimum required to destroy the principle micro-organisms, which may be found in Koi ponds. In addition thanks to the reflection produced by the stainless steel (316L) within the chamber, efficiency is increased by 20 to 30 %. Micro-organisms must, in theory be exposed for a minimum of 1 second. However, BIO-UV equipment specifications, depending on the flow rates, double the exposure time to 2 seconds, for optimal disinfecting. In order not to hinder the action of the UV-C it is important to have a high filtration quality so that large particles do not screen the radiation.

Warranties

The Bio UV Professional offers a five-year warranty on the stainless steel chamber and a full year one-year warranty on all other components (including UV lamp).  If installed according to manual.

Finally

The The Bio UV Professional system gives you the comfort of knowing that your water quality is superior to that of any other type of system, ease of installation, virtually no maintenance and optimum reliability.

Important Note: When ordering UV lamps please make sure you open the box to make sure the lamps are not broken before signing the delivery note, if the bulbs are damaged please sign the delivery note “Damaged” and refuse delivery.

A claim will ONLY be accepted if signed for as DAMAGED.

This is the Bio-UV 40 professional UVC unit

Oase Bitron Eco 180 W UVC

The revolutionary UVC clarifier Bitron Eco with 180 W power removes floating algae and harmful bacteria with maximum efficiency. Thanks to the automatic bypass regulation and the significantly enlarged housing, an optimal irradiation result is always guaranteed, even with changing flow rates of up to 50,000 l / h. The clever eco-control regulates the irradiation time depending on the seasonal needs. This enables energy savings of up to 50% to be achieved! You can also save on the light sources, because the newly developed 60W UVC lamp has a service life of 12,000 hours that is 50% longer. In addition, changing the lamp is now child’s play and without dismantling the quartz glass. The proven automatic cleaning system is also included, an LED UVC control as well as a display for lamp change and water temperature. Thanks to the protection class IP68, the Bitron Eco can be set up directly on or even in the pond. The cable length is 5 m, the nominal voltage 220 – 240/50 Hz. The Bitron Eco enables a 1 1/2 “and 2” connection. Optimal for connection to ProfiClear, BioTec 30, BioTec ScreenMatic 36. You receive a guarantee of 2 years + 1 year requirement guarantee.

• Maximum efficiency, thanks to perfect combination of flow rate and irradiation intensity
• Reduced bulb costs thanks to 50% longer service life (12,000 h)
• Energy costs reduced up to 50% with the same cleaning capacity*

Oase Bitron C 72 Watt UVC

The OASE Bitron C 72 W UVC clarifier removes floating algae and reduces harmful bacteria for healthy and clear water. An automatic cleaning system ensures fully effective UVC radiation at all times. A control window provides additional functional reliability. With a power consumption of 72 watts, 9,000 l / h can flow past the UVC tube without a bypass. The flow can be individually adjusted and regulated. The OASE Bitron C 72 W UVC clarifier is available complete with a universal stepped hose nozzle from ¾ “to 2”. The cable is 5 m long. A flow nozzle optimizes the flow to the cleaning rotor. The nominal voltage is 230 V / 50 Hz. Ideal for connection to ProfiClear, BioTec 30 and BioTec ScreenMatic 36. You receive a 2-year guarantee.

• Clever bypass system combines high flow rates with duration of radiation
• Permanent self-cleaning thanks to patented cleaning rotor
• Highly effective against suspended algae, bacteria and germs

The Amalgam Submersible UV 40

The Amalgam Submersible UV 40 watt are the most effective form of uvc to date !

The Air Aqua Amalgam provides radiation with a wavelength of 253.7nm which is generated by the special light source UV lamp, Ensuring a lethal effect on bacterial.

The  Amalgam UV radiation neutralizes bacteria, viruses and other primitive organisms, stopping them form multiplying. The unit has a built in high frequency electronic ballast which absorbs current fluctuations and protects the lamp inside the unit.

Specification:

• For Ponds up to 35 m3 – 7500 gallons
• Energy-saving: Amalgam saves 50-70% compared to normal TL-lamps
• Optimal operation up to 16,000 (amalgam) hours
• Short length: ideal for integration for Sieves or Drum Filters
• No resistance in the system (extra pipework)
• Length 50 cm

The Amalgam Submersible UV 40 watt lamp is not affected by temperature fluctuation in the water and generates a constant powerful output and is know as being the most powerful uv-c on the market !
