Kockney Koi Filter 4000

Kockney koi 8000 Fibreglass Filter

The KF8000 is available as pump fed (KF8000P) and gravity fed (KF8000G). It is a high quality, free-standing, fibreglass, three bay, filter designed to improve your fish’s environment. Its “state-of-the art” multi chamber ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of up to 8000 litres and a maximum flow rate of 6000 litres ph. However, with lighter stocking densities or in fish free ponds the KF8000 will comfortably cope with much larger volumes. Complete with multi spray bar (pump fed), filter brushes, Japanese matting and flocor. Its clever design enables it to fit through a standard 30″ domestic door opening (if required) so it can be transported through the house for those properties where there is no side or rear access. Optional matching vortex (VF1) available for gravity fed model (KF8000G).

Specifications:

8000 Litre (3 Bay) 37″ x 31.5″ x 24.5″ Deep
Maximum flow rate 6,000 litre per hour
Pump fed – Inlet size 1.5” – Outlet 110mm solvent
Gravity fed – inlet size 110mm – outlet 1.5”
Available as gravity or pump fed complete with: 2 drains and 2 Ball Valves
Media: flocor, blue matting cartridge and brushes

Both Options are supplied including media

Kockney Koi 18000V Fibreglass Filter

The KF18,000V is a high quality, free-standing, fibreglass, four bay, filter with integral vortex designed to improve your fish’s environment. Its “state-of-the art” multi chamber design ensures maximum filtration with the minimum of maintenance. The unit is suitable for fish ponds of 18,000 litres and a maximum flow rate of 11,000 litres per hour. However, with lighter stocking densities or in fish free ponds the KF18,000 will comfortably cope with much larger volumes. The integral Vortex enhances the unit’s performance and reduces the maintenance intervals

Specifications:

The media package consists of:
Bay 1: Eighteen 16″ long x 8″ diametre polypropylene filter brushes – They are of a semi-rigid construction with a wire loop at the end for easy cleaning.
Bay 2: Blue matting – This is an excellent filter media as it has a large surface area giving it an excellent bio-mass retention. Its open texture removes larger particles from the water.
Bay 3: Three layers of reticulated foam with different density of porosity of each layer. This is on top of a layer of approximately 2 cubic foot of flocor.
Bay 4: Six way foam block manifold assembly on top of six cubic foot of Flocor. The large surface area of Flocor tubes makes it an ideal filter media.

102 ” long x 33” wide x 32” Deep
Maximum flow rate 11,000 litre per hour
Three drainage points – (Accepts 1.5″ solvent weld pipe for remote drainage)
Supplied with 3 x 1.5″ Kockney Koi Ball Valves (Not shown)
The gravity fed model has a 4″ inlet and 1.5″ outlet where the pump fed model has a 1.5″ inlet and 4″ outlet.

Both Options are supplied including media
