Description
Oase Filtral UVC 9000
The Oase Filtral UVC 9000 is a compact all-rounder for small ponds, to supplement a filter system, or suitable for decorative pools such as zinc tubs or barrels. The compact underwater filter with UVC technology for sterilisation also has the option for various water fountain attachments and an aeration nozzle from the Filtral UVC 3000 onwards. Four different filter materials ensure clear water.
The filter component includes a coarse and fine filter foam, as well as bio-surface elements and ceramic media to ensure both mechanical and biological filtration.
Features:
- Multifunctional compact solution for pre-fabricated pools and smaller ponds
- Clear water, guaranteed, and beautiful fountains
- The technology is virtually invisible because it is set up underwater
Characteristics:
- MULTI-TALENTED: With filter function, water feature and aeration nozzle (aeration nozzle included in delivery, from Filtral UVC 3000)
- GUARANTEED: Includes OASE clear water guarantee
- ADJUSTABLE: Adjustable Y-distributor, for operating water spouts or small watercourses
- CONTROL SYSTEM: Individual adjustments of water flow and fountain height
- CONCEALED: Installation completely underwater – ensuring that the overall appearance of the pond remains undisturbed
- OVERVIEW: Thanks to UVC clarifier with optical function check
Technical Data:
| Dimensions (L x W x H) | mm | 347 x 276 x 157 |
|---|---|---|
| Rated voltage | 230 V / 50 Hz | |
| Power consumption | W | 52 |
| Power cable length | m | 10.00 |
| Net weight | kg | 5.30 |
| Guarantee | Years | 2 |
| UVC power | W | 13 |
| Pump capacity, max. | l/h | 2500 |
| Max. flow rate | l/h | 1700 |
| Max. head height, metres | m | 2.10 |
| Filter intake surface | cm2 | 697 |
| Number of blue filter foams | Units | 1 |
| Number of red filter foams | Units | 1 |
| Number of bio-surface elements | Units | 4 |
| Special filter granulate | kg | 0.80 |
| Pressure-side connection | ½”, ¾”, 1″ | |
| Suitable for ponds up to max. | m3 | 9.0 |
| Suitable for ponds with fish stock | m3 | 4.5 |
| Aeration set included in the scope of delivery | Yes |
