Oase ProfiClear Premium Individual Module
  • Oase ProfiClear Premium Individual Module
  • Oase ProfiClear Premium Individual Module

Oase ProfiClear Premium Individual Module

£1,444.49 inc. VAT

Oase ProfiClear Premium Individual Module Filter

The Oase ProfiClear Premium Individual Module Filter is ideal for both professional and new pond keepers too, giving you the best water quality possible through sophisticated technology.

Premium Gravity filters are modular in design, meaning they can be connected together in separate ways in order to create a tailored system to suit virtually any pond size.

The Individual Module allows for easy installation of Aquamax Gravity Eco filter pumps or Bitron Gravity UVC products.

Pre-installed within the Filter box are stainless steel baskets for addition extra filter materials from A (active carbon) to Z (Zeolite).

DN100 pipework allows for multiple installation configurations to suit your needs with minimal pressure loss.

3-year Guarantee after registering your item with Oase.

ProfiClear Individual Module Features:

Max Flow Rate of up to 25,000 Litres Per Hour
Minimum Flow Rate of 10,000 Litres Per Hour
Includes 2x 8 Litre Stainless Steel Baskets for Filter Material
Typically used as part of a Pumping or Gravity Fed System

SKU: FS198 (50771) Categories: ,

Description

Oase ProfiClear Premium Individual Module

The Oase ProfiClear Premium Individual Module Filter is ideal for both professional and new pond keepers too, giving you the best water quality possible through sophisticated technology.

Premium Gravity filters are modular in design, meaning they can be connected together in separate ways in order to create a tailored system to suit virtually any pond size.

The Individual Module allows for easy installation of Aquamax Gravity Eco filter pumps or Bitron Gravity UVC products.

Pre-installed within the Filter box are stainless steel baskets for addition extra filter materials from A (active carbon) to Z (Zeolite).

DN100 pipework allows for multiple installation configurations to suit your needs with minimal pressure loss.

3-year Guarantee after registering your item with Oase.

ProfiClear Individual Module Features:

Max Flow Rate of up to 25,000 Litres Per Hour
Minimum Flow Rate of 10,000 Litres Per Hour
Includes 2x 8 Litre Stainless Steel Baskets for Filter Material
Typically used as part of a Pumping or Gravity Fed System

Characteristics:

  • Mature, professional technology with more than three years of development time
  • Space saving pump and UVC chamber for
  • Maximum flexibility in the connection through 2 x DN110 and 2″ transitions
  • To increase the filter capacity, it is possible to fill the individual baskets in the flow area with additional filter media – up to 8 litres fill volume
  • Integrated bottom drain with high quality, finely engineered slide valve
  • Flexible adaptation of the filter system to individual requirements (individual module)
  • Innovative and reliable product »Made in Germany
TECHNICAL DATA
Dimensions (L x W x H) mm 830 x 600 x 820
Net weight kg 37.00
Guarantee (+ request guarantee) Years 2 + 1
Material GRP Duroplast/stainless steel
Number of inlets Units 2
Inlet connections mm 180
Inlet connections 2 x 185 mm
Number of outlets Units 4
Connections, outlet mm 50
Outlet connections 2 x 2″ / 2 x DN 110
Sludge discharge connections DN 75
Connection to AquaMax Eco Gravity, Bitron Gravity
Min. flow rate l/h 10000
Max. flow rate l/h 33000
Installation height above water level cm 11.5
Type of use Gravity fed system, Pump fed system
Other Pollutant discharge incl. slide valve

Reviews

There are no reviews yet

Only logged in customers who have purchased this product may leave a review.

Manual





Oase ProfiClear Premium Individual Module.pdf

Q & A

There are no questions yet

Ask a question

Your question will be answered by a store representative or other customers.

Thank you for the question!

Your question has been received and will be answered soon. Please do not submit the same question again.

Error

Warning

An error occurred when saving your question. Please report it to the website administrator. Additional information:

Add an answer

Thank you for the answer!

Your answer has been received and will be published soon. Please do not submit the same answer again.

Error

Warning

An error occurred when saving your answer. Please report it to the website administrator. Additional information:

Additional information

Weight 50 kg
Dimensions 80 × 80 × 80 cm
